線性模組使用本體與滑座一體成型鋼材，改善線性模組原始鋁滑座剛性較差的問題

Actuator body and carriage are made from steel that can improve the rigidness of body and carriage

● 線性模組不需拆卸鋼帶，即可由上往下固定或由下往上固定

Canbe fixed from the top and bottom without removing the cover

● 直線模組本體側面增加安裝基準面承靠

Mounting datum plane designed on the side of the body

● 直線模組本體底部有定位PIN孔

Built in pin holes

直線模組采用特殊鋼帶結構設計，可減少發塵。電動滑臺可用于潔凈室內環境。

Special steel strip cover sealing design can prevent dirt and foreign objiects from penetrating inside

直線模組軌道嵌入于本體后研磨，行走等高直線度可達±0.02mm

Built in linear rail design, Straightness and Flatness are highly improved to ±0.02mm

寬度縮小，讓設備安裝所需空間更小

Rudeced width that can be fited in the compact environments.

自潤滑結構設計，直線模組可實現輕負載30000km免維護

Self-lubricating design can achieve light load and 30000km maintenance free

● 直線模組自潤滑塊有毛細作用始終儲存和供給潤滑油

The self-lubricating block has a capillary action to always store and supply, the lubricating oil.

● 直線模組自潤滑塊安裝在密封端蓋與滾動體之間，直接與溝道接觸，潤滑油供給在滾道上，當滾動體在溝道經過，起到潤滑作用

The self-lubricating block is installed between the sealing end cover and the rolling body, and is in direct contact with the channel, and the lubricating oil is supplied on the raceway, and the rolling body passes through the channel to provide lubrication.
